The primary purpose of the refrigerated truck XPS foam board is to regulate air circulation and partition the vehicle into distinct temperature zones. Extruded XPS foam boards come in two types: standard and temperature-controlled. Temperature-controlled XPS foam boards are equipped with temperature control mechanisms and fans to precisely regulate the temperature within each zone.
Physical And Mechanical Properties
Item
Unit
Performance
Smooth Surface
X150
X200
X250
X300
X400
X450
X500
Compressive strength
Kpa
≥150
≥200
≥250
≥300
≥400
≥450
≥500
Size
Length
MM
1200/2000/2400/2440
Width
MM
600/900/1200
Thickness
MM
10/20/25/30/40/50/60/70/80/100
Water absorption rate, water seepage 96h
%(Volume fraction)
≤1.0
≤1.0
GB/T 10295-2008 Thermal Conductivity
Average temperature of 25℃
W/(m.K)
≤0.034
≤0.033
Density
kg/m³
28-38
Remark
Product size, density, compressive strength, thermal conductivity support customization
Product Advantage
1. Exceptional Thermal Insulation: XPS foam boards boast low thermal conductivity, effectively containing interior cold air and repelling external heat. This stability maintains consistent internal temperatures within refrigerated trucks, alleviating strain on refrigeration systems and reducing energy consumption.
2. Robust and Resilient: With high hardness and compression resistance, XPS foam boards withstand prolonged pressure and vibration without deformation. This durability safeguards cargo against damage during transit and sustains optimal insulation performance.
3. Waterproof and Moisture-Resistant: Featuring a closed-cell structure, XPS foam boards resist water absorption, preserving insulation efficacy even in humid environments. This prevents degradation of thermal performance due to moisture and mitigates condensation issues inside compartments.
4. Lightweight Design: XPS foam boards exhibit lower density compared to traditional insulation materials, reducing vehicle weight. This enhancement contributes to improved fuel efficiency and maximizes effective cargo space.
5. Effortless Installation: Precisely cut XPS foam panels effortlessly adhere to vehicle dimensions, facilitating quick and simple construction processes.
6. Longevity and Reliability: With excellent aging resistance, XPS foam boards maintain thermal insulation performance over extended periods of use, ensuring sustained durability.
7. Environmentally Conscious and Recyclable: Many XPS foam board products utilize eco-friendly materials, minimizing harmful substance emissions during production and usage. Moreover, waste materials can be recycled and repurposed to reduce environmental impact.
8. Hygienic and Safe: Smooth XPS foam board surfaces discourage bacterial growth, making them ideal for food transport and compliant with stringent hygiene standards.
Product Uses
Here are four specific application scenarios of packaging machinery:
1、Cold storage cold chain insulation
2、Building roof insulation
3、Steel structure roof
4、Building wall insulation
5、Building ground moisturising
6、Square ground
7, Ground frost control
8, Central air-conditioning ventilation ducts
9, Airport runway heat insulation layer
10, High-speed railway roadbed, etc.
Product Operate Guide
1. Begin by carefully selecting insulation materials renowned for their exceptional heat preservation capabilities. These materials are then positioned within the steel plate framework and meticulously enveloped around the truck's body. Common choices include polyurethane and rigid polyurethane insulation materials.
2. During the insulation material installation phase, meticulous attention is required to prevent any gaps from forming between the layers. This meticulous approach is essential to ensure optimal thermal insulation performance.
3. To secure the insulation material firmly to the steel plate, various bonding methods can be employed, such as using rivets or rings. These techniques provide additional reinforcement to uphold the insulation material in place effectively."
