The primary purpose of the XPS foam board in refrigerated trucks is to regulate air circulation and partition the vehicle into distinct temperature zones. Extruded XPS foam boards come in two varieties: standard extruded XPS foam boards and temperature-controlled extruded XPS foam boards. The latter is equipped with temperature control devices and fans to precisely manage the temperature within the designated zones.
Physical And Mechanical Properties
Item
Unit
Performance
Smooth Surface
X150
X200
X250
X300
X400
X450
X500
Compressive strength
Kpa
≥150
≥200
≥250
≥300
≥400
≥450
≥500
Size
Length
MM
1200/2000/2400/2440
Width
MM
600/900/1200
Thickness
MM
10/20/25/30/40/50/60/70/80/100
Water absorption rate, water seepage 96h
%(Volume fraction)
≤1.0
≤1.0
GB/T 10295-2008 Thermal Conductivity
Average temperature of 25℃
W/(m.K)
≤0.034
≤0.033
Density
kg/m³
28-38
Remark
Product size, density, compressive strength, thermal conductivity support customization
Product Advantage
1. Exceptional Thermal Insulation: The XPS foam board boasts low thermal conductivity, effectively retaining internal cold air while resisting outside heat intrusion. This ensures stable internal temperatures in refrigerated trucks, alleviating strain on refrigeration equipment and reducing energy consumption.
2. Robust and Resilient: With high hardness and compressive strength, the XPS foam board withstands prolonged pressure and vibration, maintaining its shape and safeguarding cargo against wall damage. Its structural integrity preserves optimal insulation performance.
3. Waterproof and Moisture-Resistant: Featuring a closed-cell structure, the XPS foam board repels water, sustaining thermal insulation efficacy even in humid environments. This prevents moisture-related degradation of thermal performance and eliminates issues like condensation on compartment walls.
4. Lightweight Construction: Compared to conventional insulation materials, the XPS foam board boasts lower density, reducing vehicle weight. This enhances fuel efficiency and maximizes cargo capacity within the vehicle.
5. Easy Installation: Precisely cut XPS foam panels adhere easily to vehicle dimensions, facilitating swift and straightforward installation.
6. Longevity and Reliability: Resistant to aging, the XPS foam board maintains optimal thermal insulation performance over extended periods of use, ensuring enduring durability.
7. Environmentally Conscious and Recyclable: Some XPS foam board products utilize eco-friendly raw materials and emit fewer harmful substances during production and use. Moreover, waste materials can be recycled and repurposed to minimize environmental impact.
8. Hygienic and Safe: Ideal for food transport, the smooth surface of the XPS foam board discourages bacterial growth, meeting stringent food safety and hygiene standards.
Product Uses
Here are four specific application scenarios of packaging machinery:
1、Cold storage cold chain insulation
2、Building roof insulation
3、Steel structure roof
4、Building wall insulation
5、Building ground moisturising
6、Square ground
7, Ground frost control
8, Central air-conditioning ventilation ducts
9, Airport runway heat insulation layer
10, High-speed railway roadbed, etc.
Product Operate Guide
1. Choose insulation material renowned for its superior heat preservation capabilities. Install it within the steel plating and encompass it around the vehicle's body. Suitable options include polyurethane and rigid polyurethane insulation materials.
2. While laying the insulation materials, meticulous attention must be given to prevent any gaps, ensuring optimal thermal insulation performance.
3. Secure the bonding between the insulation material and the steel plate using methods like riveting or fastening rings to reinforce the fixation of the insulation material."
