Internal and external wall insulation foam panels find extensive application across diverse settings, including new constructions and refurbishment projects for both internal and external wall insulation. They offer significant enhancements to thermal insulation and comfort levels within buildings while concurrently contributing to reduced energy consumption, aligning with global initiatives for energy efficiency and sustainable building practices. This versatile solution sees widespread adoption in various sectors, including residential, commercial, and public infrastructure projects.
Physical And Mechanical Properties
Item
Unit
Performance
Smooth Surface
X150
X200
X250
X300
X400
X450
X500
Compressive strength
Kpa
≥150
≥200
≥250
≥300
≥400
≥450
≥500
Size
Length
MM
1200/2000/2400/2440
Width
MM
600/900/1200
Thickness
MM
10/20/25/30/40/50/60/70/80/100
Water absorption rate, water seepage 96h
%(Volume fraction)
≤1.0
≤1.0
GB/T 10295-2008 Thermal Conductivity
Average temperature of 25℃
W/(m.K)
≤0.034
≤0.033
Density
kg/m³
28-38
Remark
Product size, density, compressive strength, thermal conductivity support customization
Product Advantage
1. Thermal Insulation: XPS foam board has a high R-value, meaning it provides excellent thermal insulation. This helps in maintaining a comfortable indoor temperature while reducing the need for heating or cooling, thus saving energy and lowering utility bills.
2. Moisture Resistance: XPS foam board is resistant to moisture, preventing water infiltration into the walls. This property helps in maintaining the integrity of the insulation system and prevents the growth of mold and mildew, which can be harmful to indoor air quality and the structural integrity of the building.
3. Durability: XPS foam board is a rigid and durable material that can withstand the stresses of construction and provide long-term insulation performance. It is resistant to compression, making it suitable for use in both interior and exterior applications.
4. Easy Installation: XPS foam boards are lightweight and easy to handle, cut, and install. They can be easily fitted into wall cavities, reducing installation time and labor costs.
5. Versatility: XPS foam boards can be used for both interior and exterior insulation applications. They can be installed in various wall types, including concrete, masonry, and wood framing, making them a versatile choice for different construction projects.
6. Fire Resistance: XPS foam board is inherently fire-resistant, adding an extra layer of safety to the building. In case of a fire, XPS foam board does not contribute to the spread of flames and helps in slowing down the fire's progression.
7. Environmental Benefits: XPS foam board is manufactured with low global warming potential blowing agents, making it an environmentally friendly insulation option. Additionally, its long lifespan and energy-saving properties contribute to reducing the overall carbon footprint of the building.
8. Cost-Effectiveness: While the initial cost of XPS foam board may be higher compared to some other insulation materials, its long-term benefits in terms of energy savings, durability, and maintenance make it a cost-effective choice for insulation systems.
Product Uses
Here are four specific application scenarios of packaging machinery:
1、Cold storage cold chain insulation
2、Building roof insulation
3、Steel structure roof
4、Building wall insulation
5、Building ground moisturising
6、Square ground
7, Ground frost control
8, Central air-conditioning ventilation ducts
9, Airport runway heat insulation layer
10, High-speed railway roadbed, etc.
Product Operate Guide
1. Effective Thermal Insulation: The extruded plastic board, both internally and externally, boasts ultra-low thermal conductivity. This property prevents heat loss during cold winters and reduces heat penetration in scorching summers. Consequently, it significantly diminishes the need for air conditioning and heating, enhancing overall energy efficiency.
2. Robust Structural Integrity: Thanks to its unique closed-cell honeycomb structure, the extruded plastic board exhibits remarkable compressive strength and impact resistance. Whether on the exterior or interior walls, it maintains stable form over extended periods, effectively withstanding external pressure and wind loads.
3. Waterproof and Moisture-Resistant: Its non-absorbent nature serves as a barrier against moisture infiltration. For exterior walls, it shields against rain erosion, preserving the structural integrity. Internally, it helps regulate indoor humidity, ensuring dry walls and extending the building's lifespan.
4. Superior Stability: Extruded plastic panels maintain dimensional stability even in extreme temperatures. They resist excessive contraction or expansion due to temperature fluctuations, mitigating risks of wall cracks or spalling.
5. Easy Installation: Lightweight and easily customizable, extruded plastic boards simplify installation. They can be tailored to fit various wall sizes and effortlessly installed using bonding, anchoring, or other methods, reducing construction time and labor costs.
6. Environmental Friendliness: Produced without harmful substances, high-quality extruded plastic panels align with modern energy-saving and environmentally friendly construction practices. With a long lifespan and recyclable nature, they contribute to sustainable building solutions.
