Internal and external wall insulation foam panels find extensive application across a spectrum of new and established structures, including renovation projects for both external and internal wall insulation. These panels not only enhance thermal insulation and comfort within buildings but also contribute to reducing energy consumption, aligning with global initiatives for energy conservation and emission reduction, as well as the growing trend towards green construction practices. Their versatility extends across diverse sectors, encompassing civil housing, commercial edifices, and public buildings.
Physical And Mechanical Properties
Item
Unit
Performance
Smooth Surface
X150
X200
X250
X300
X400
X450
X500
Compressive strength
Kpa
≥150
≥200
≥250
≥300
≥400
≥450
≥500
Size
Length
MM
1200/2000/2400/2440
Width
MM
600/900/1200
Thickness
MM
10/20/25/30/40/50/60/70/80/100
Water absorption rate, water seepage 96h
%(Volume fraction)
≤1.0
≤1.0
GB/T 10295-2008 Thermal Conductivity
Average temperature of 25℃
W/(m.K)
≤0.034
≤0.033
Density
kg/m³
28-38
Remark
Product size, density, compressive strength, thermal conductivity support customization
Product Advantage
1. High Insulation Value: XPS (Extruded Polystyrene) foam board has a high R-value per inch of thickness, meaning it provides excellent insulation against heat transfer. This helps to maintain comfortable temperatures inside the building and reduces the need for heating or cooling, thereby saving on energy costs.
2. Moisture Resistance: XPS foam board is resistant to moisture, making it suitable for use in areas prone to dampness or humidity. This moisture resistance helps to prevent mold, mildew, and rot from developing within the walls, thus preserving indoor air quality and structural integrity.
3. Durable and Long-lasting: XPS foam board is a durable material that can withstand the rigors of construction and installation. It is resistant to compression, which helps maintain its insulation properties over time. Additionally, it does not degrade or deteriorate easily, ensuring long-term performance.
4. Ease of Installation: XPS foam board is lightweight and easy to handle, making it convenient to install in both interior and exterior walls. It can be cut to size with ordinary tools and attached to the walls using adhesive, mechanical fasteners, or both, depending on the specific application.
5. Versatility: XPS foam board is available in various thicknesses and sizes, allowing for flexibility in design and construction. It can be used in conjunction with other insulation materials or as part of a multi-layered insulation system to achieve higher levels of energy efficiency.
6. Fire Resistance: XPS foam board has a relatively high resistance to fire, making it a safe choice for use in building construction. It does not easily ignite or contribute to the spread of flames, which can help to contain fires and protect occupants in the event of an emergency.
7. Sound Insulation: In addition to thermal insulation, XPS foam board also provides some degree of sound insulation, helping to reduce noise transmission between rooms or from external sources.
Overall, the use of XPS foam board in an interior and exterior wall insulation system offers numerous benefits, including energy savings, moisture resistance, durability, ease of installation, versatility, fire resistance, and sound insulation.
Product Operate Guide
Here are four specific application scenarios of packaging machinery:
1、Cold storage cold chain insulation
2、Building roof insulation
3、Steel structure roof
4、Building wall insulation
5、Building ground moisturising
6、Square ground
7, Ground frost control
8, Central air-conditioning ventilation ducts
9, Airport runway heat insulation layer
10, High-speed railway roadbed, etc.
Product Uses
1. Enhanced Thermal Efficiency: The internal and external wall insulation provided by extruded plastic boards boasts ultra-low thermal conductivity. This feature effectively curbs heat loss during chilly winters and restricts heat infiltration on scorching summer days. Consequently, it significantly slashes the need for air conditioning and heating, elevating overall energy efficiency.
2. Robust Structural Integrity: With its distinctive closed-cell honeycomb configuration, extruded plastic boards exhibit remarkable compressive strength and impact resistance. Whether safeguarding exterior or interior walls, they uphold structural stability over prolonged periods, adeptly withstanding external pressures and wind forces.
3. Waterproof and Moisture-Resistant: Impermeable by nature, these boards serve as a barrier against moisture intrusion. For external walls, they shield against rain-induced erosion, while for internal partitions, they mitigate indoor humidity levels, ensuring a dry environment and extending the building's lifespan.
4. Unwavering Stability: Even amidst fluctuating temperatures, extruded plastic panels maintain impeccable dimensional consistency. This resilience negates the risk of wall fissures or disintegration caused by thermal expansion or contraction, ensuring enduring structural integrity.
5. Effortless Installation: Lightweight and easily adaptable, extruded plastic boards facilitate seamless customization for diverse wall dimensions. Installation is a breeze, accomplished through bonding, anchoring, or other methods, promoting swift construction and minimizing labor expenses.
6.Eco-Friendly Credentials: Manufactured without harmful substances, high-quality extruded plastic panels align with modern energy-efficient and environmentally conscious construction practices. Furthermore, their extended lifespan and recyclability upon disposal contribute to sustainable building initiatives.
