High Compression Rigid 100mm Thick Pink Xps Foam Board

Shanghai Taichun Energy Saving Technology is your trusted manufacturer of high-performance insulation solutions, including High Compression Rigid 100mm Thick Pink XPS Foam Board. We offer XPS foam boards designed to fit various construction and insulation needs. You can rely on the strength, durability, and thermal efficiency of our XPS foam boards. Share your project requirements, and we will provide the ideal insulation solution for you.
Availability:
Quantity:
Product Introduction

Our high-performance insulation XPS foam board for basements is engineered with precision to meet the unique insulation needs of below-ground spaces. The board features a dense and uniform cellular structure, which is achieved through advanced manufacturing processes. This structure forms an effective thermal barrier, minimizing heat transfer between the basement and the outside environment.


The surface of the XPS foam board is smooth and flat, facilitating easy installation. It can be directly applied to the basement walls, floors, or ceilings with a variety of adhesives or mechanical fasteners. The edges of the board are carefully cut to ensure a snug fit, reducing the risk of air leakage and enhancing the overall insulation performance.


To further enhance its functionality, some of our XPS foam boards are available with a special moisture-resistant coating. This coating not only protects the board from moisture absorption but also prevents the growth of mold and mildew, which are common issues in basements. Additionally, the board can be customized in terms of thickness, ranging from thin layers for spaces with limited installation room to thicker ones for areas that require maximum insulation.

Physical And Mechanical Properties
Item Unit Performance
Smooth   Surface
X150 X200 X250 X300 X400 X450 X500
Compressive strength Kpa ≥150 ≥200 ≥250 ≥300 ≥400 ≥450 ≥500
Size Length MM 1200/2000/2400/2440
Width MM 600/900/1200
Thickness MM 10/20/25/30/40/50/60/70/80/100
Water absorption rate, water seepage 96h %(Volume fraction) ≤1.0 ≤1.0
GB/T 10295-2008 Thermal Conductivity Average   temperature of 25℃ W/(m.K) ≤0.034 ≤0.033
Density kg/m³ 28-38
Remark Product size, density,   compressive strength, thermal conductivity support customization


xps foam board (11)

Product Advantages

One of the most remarkable features of our XPS foam board is its exceptional thermal insulation property. With a low thermal conductivity, it effectively blocks heat from escaping in the winter and entering in the summer. This helps to maintain a comfortable temperature in the basement, reducing the energy consumption of heating and cooling systems. Whether you use the basement as a living space, a storage area, or a workshop, our XPS foam board can significantly improve the energy efficiency of the area.


Another key feature is its high compressive strength. The dense cellular structure of the XPS foam enables the board to withstand heavy loads, making it suitable for basement floors that may bear the weight of furniture, equipment, or even vehicles in some cases. It can support the weight without deforming or collapsing, ensuring the long-term stability of the basement structure.


Our XPS foam board also offers excellent moisture resistance. The closed-cell structure of the foam prevents water from penetrating the board, protecting the underlying building materials from water damage. The additional moisture-resistant coating further enhances this property, making the board highly durable in the often-humid environment of basements. Moreover, the board is resistant to pests and chemicals, adding to its longevity.


FAQs

Q1: Can the XPS foam board be installed on existing basement walls without major renovations?

A: Yes, our XPS foam board can be installed on existing basement walls with relative ease. However, it is important to ensure that the walls are clean, dry, and in good condition before installation. If there are any cracks, holes, or signs of water damage, these should be repaired first. In most cases, the board can be attached using adhesives or mechanical fasteners, and it may not require major renovations to the existing walls. Our technical team can provide detailed installation guidelines to ensure a successful installation.

Q2: How long does the XPS foam board last in a basement environment?

A: Our XPS foam board has a long lifespan when properly installed and maintained in a basement environment. Under normal conditions, it can last for 20 to 30 years or even longer. The board's resistance to moisture, pests, and chemicals, along with its durable construction, contributes to its longevity. However, factors such as the quality of installation, the level of humidity in the basement, and exposure to extreme temperatures may affect its lifespan. Regular inspection and maintenance can help to extend the life of the board.

Q3: Is the XPS foam board fire-resistant?

A: Our XPS foam board has a certain level of fire resistance. It is treated with flame-retardant additives to meet specific fire safety standards. While it is not completely fireproof, it can help to slow down the spread of flames and heat in case of a fire, providing more time for evacuation and fire suppression. It is important to note that proper installation and compliance with local building codes are necessary to ensure the fire safety of the basement.

Q4: Can the thickness of the XPS foam board be adjusted according to my insulation needs?

A: Yes, we offer a range of thickness options for our XPS foam board to meet different insulation needs. You can choose the appropriate thickness based on factors such as the climate of your area, the intended use of the basement, and the level of insulation required. Our sales team can provide professional advice and help you determine the most suitable thickness for your specific situation.
